Model | MAH50 |
Detector Parameters |
Resolution, pixels | 640 × 512 |
Pixel size, um | 12 |
NETD, mk | ≤ 25 |
Frame rate, Hz | 50 |
Optics Parameters |
Objective lens, mm | 50 |
Field of view (H x V), degrees / m @ 100 m | 8.8 × 7.0 / 15.4 × 12.3 |
Recommended magnification of the day scope, x | G1/G2: 1 - 5 |
G3/G4: 6 - 10 |
E-zoom | Attachment mode: ×1 |
Monocular mode: ×1/×2/×4 |
Detection range, m | 2597 |
(Target size: 1.7m×0.5m, P(n)=99%) |
Display Parameters |
Type | OLED |
Resolution, pixels | 1024 × 768 |
Electrical Parameters |
Battery | Built-in battery + Infiray battery Pack |
Max. battery life, h | 4 + 7 |
USB Interface | Type-C |
Physic Parameters |
Body Material | Magnesium Alloy |
IP Rating | IP67 |
Remote control | Support |
Built-in memory, GB | 32 |
Aim point, MOA | 1 |
Weight, g | 530 |
Dimension, mm | 146 × 62 × 73 |
Adapter Ring | M52×0.75 |
